MouseBlocker 1000x - Rodent Protection

The MouseBlocker 1000 is next level protection for your garage, to guard your vehicle and equipment from the costly damage caused by mice, rats, squirrels, and other rodents. Designed to protect up to 1000-sq. ft - (2-4 car garage)-the device features four high-powered speakers that release high-frequency, ultrasonic sounds, in varying frequencies/patterns to deter rodents from the area. Operates on standard 110v AC power plug. Measures 21” x 7” x 9”.

Function
The MouseBlocker 1000x uses modern micro-electronics technology outputting 2 types of special ultrasonic waves simultaneously. These waves act upon the hearing and nervous system of rodents making them unpleasant and uncomfortable. This unit is designed to drive the mice away from protected areas. The frequencies output from the 1000x are constantly changing and alternating eliminating the chance of rodents adapting to the sound.

Coverage Area
The MouseBlocker 1000x is a very high output device covering up to 1000 square feet with a clear line of site. Since the unit operates off sound, the noise will not go thru walls or solid objects. Place the unit with speakers facing open space free of obstructions

Operation Methods

1. Plug one end of the included power cord into the power socket on the left rear side of the unit. Plug the other end of the power cord into any available 110v power outlet.
2. After pluggin the unit into power, it will start working imediately.
3. The green power light should be on solid and the blue ultrasonic light should be flashing/blinking according to the sound output.

Testing output: There is a green test button on the back of the unit. Pressing this button will amplify the ultra sonic noise to an audible level. This noise is very loud and confirms that the microproccessor is working properly.

Precautions

1. Never use the device outdoors, in high temperature locations or damp locations.
2. The MouseBlocker 1000x should be used continuously without stopping to be effective
3. There should be no obstructions in front of the unit. Ultrasonic noises will not pass thru hard objects.
4. There are four loud speakers installed in three directions so the device should be installed along a wall,
   with the back facing a wall for optimal effectiveness.
5. It is normal if the device gets warm to the touch.
6. The effects of this unit will be seen immediately as soon as the device is powered on. The unit will be most
   effective after using it continuously for 3-4 weeks. Sometimes the mice may be more active during the
   begining of use showing that the rodents are irritated. After using the unit for a prolong period of time the
   mice will begin to dissapear.

Unit Technical Specifications

• AC Power Voltage: AC 120v 60hz
• Power Consumption: 25Watts
• Frequency Coverage: 25-45Khz Intermittent at 160 Seconds

WARNING: This unit is LOUD , at least 15 times louder than any other unit on the market today and more than 100 times louder than the little plug in units the department stores sell (trust us we tested them all) and on the highest settings most humans can hear the sounds emitted as will some household pets like cats and dogs. The sounds WILL NOT harm them in any way you will just notice the animals will leave the area the unit is located and if under the hood of your vehicle the sounds for the most part will be contained to the engine compartment anyways.
